RS 200

Sailboat specifications

The RS 200 is a 13’1” (4m) double handed skiff (dinghy) designed by Phil Morrisson (United Kingdom). She is built since 1995 by RS Sailing (United Kingdom).

RS 200's main features

Model: RS 200
Hull type: Monohull
Category: Double handed skiff (dinghy)
Sailboat builder: RS Sailing
Sailboat designer: Phil Morrisson
Country: United Kingdom
Construction: GRP (glass reinforced polyester):
Sandwich foam fiberglass polyester
First built hull: 1995
Last built hull: Still in production
Appendages: Centerboard : pivoting centerboard
Helm: Single tiller
Rudder: Single transom hung rudder
Unsinkable: No
Trailerable: Yes
Former French navigation category: 2
Standard public price ex. VAT (indicative only): About
11 600 €
(2020)

RS 200's main dimensions

Hull length: 13’ 1”4 m
Beam (width): 6’1.83 m
Draft: 3’ 8”1.13 m
Light displacement (M_LC): 251 lb114 kg

RS 200's rig and sails

Upwind sail area: 128 ft²11.89 m²
Downwind sail area: 188 ft²17.42 m²
Mainsail area: 98 ft²9.13 m²
Genoa area: 30 ft²2.76 m²
Asymmetric spinnaker area: 89 ft²8.29 m²
Rigging type: Sloop Marconi fractional
Mast configuration: Deck stepped mast
Rotating spars: No
Number of levels of spreaders: 1
Spreaders angle: Swept-back
Spars construction: Aluminum spars
Standing rigging: Continuous

RS 200's performances

Crew: 2
PY (Portsmouth Yardstick) rating iPortsmouth Yardstick is an empirical rating system allowing small sailboats (dinghies included), of different sizes and designs, to race each other fairly. Therefore, by comparing these values, we can have an indication of the relative speed of 2 boats.: 1057
D-PN rating iDPN is a variation of Portsmouth Yardstick used in the United States.: 88.3
Upwind sail area to displacement iThe ratio sail area to displacement is obtained by dividing the sail area by the boat's displaced volume to the power two-thirds. The ratio sail area to displacement can be used to compare the relative sail plan of different sailboats no matter what their size. Upwind: under 18 the ratio indicates a cruise oriented sailboat with limited performances especially in light wind, while over 25 it indicates a fast sailboat.: 544 ft²/T50.57 m²/T
Downwind sail area to displacement iThe ratio sail area to displacement is obtained by dividing the sail area by the boat's displaced volume to the power two-thirds. The ratio sail area to displacement can be used to compare the relative sail plan of different sailboats no matter what their size.: 797 ft²/T74.09 m²/T
