Moody 33S

Sailboat specifications

The Moody 33S is a 33’ (10.06m) cruising sailboat designed by Angus Primrose (United Kingdom). She was built between 1979 and 1982 by Moody (United Kingdom).

Moody 33S's main features

Model: Moody 33S
Hull type: Monohull
Category: Cruising sailboat
Sailboat builder: Moody
Sailboat designer: Angus Primrose
Country: United Kingdom
Construction: GRP (glass reinforced polyester):
- Hull: Single skin fiberglass polyester
- Deck: Single skin fiberglass polyester
First built hull: 1979
Last built hull: 1982
Appendages: Keel : fin without bulb
Helm: Single helm wheel
Rudder: Single rudder on skeg
Unsinkable: No
Trailerable: No
EC design category iThe CE design category indicates the ability to cope with certain weather conditions (the sailboat is designed for these conditions) A: Wind < force 9, Waves < 10m B: Wind < force 8, Waves < 8m C: Wind < force 6, Waves < 4m D: Wind < force 4, Waves < 0,5m: 2
Standard public price ex. VAT (indicative only): N/A €

Moody 33S's main dimensions

Hull length: 33’10.06 m
Waterline length: 28’ 6”8.69 m
Beam (width): 11’ 6”3.51 m
Draft: 4’ 5”1.35 m
Light displacement (M_LC): 10505 lb4765 kg
Ballast weight: 3814 lb1730 kg

Moody 33S's rig and sails

Upwind sail area: 580 ft²53.89 m²
Mainsail area: 205 ft²19.05 m²
Genoa area: 375 ft²34.84 m²
Solent area: 278 ft²25.83 m²
Jib area: 176 ft²16.35 m²
Stormjib area: 74 ft²6.87 m²
Rigging type: Sloop Marconi masthead
Mast configuration: Deck stepped mast
Rotating spars: No
Number of levels of spreaders: 1
Spreaders angle: 0 °
Spars construction: Aluminum spars
Standing rigging: 1x19 strand wire continuous

Moody 33S's performances

Upwind sail area to displacement iThe ratio sail area to displacement is obtained by dividing the sail area by the boat's displaced volume to the power two-thirds. The ratio sail area to displacement can be used to compare the relative sail plan of different sailboats no matter what their size. Upwind: under 18 the ratio indicates a cruise oriented sailboat with limited performances especially in light wind, while over 25 it indicates a fast sailboat.: 205 ft²/T19.03 m²/T
Displacement-length ratio (DLR) iThe Displacement Length Ratio (DLR) is a figure that points out the boat's weight compared to its waterline length. The DLR is obtained by dividing the boat's displacement in tons by the cube of one one-hundredth of the waterline length (in feet). The DLR can be used to compare the relative mass of different sailboats no matter what their length: a DLR less than 180 is indicative of a really light sailboat (race boat made for planning), while a DLR greater than 300 is indicative of a heavy cruising sailboat.: 206
Ballast ratio iThe Ballast ratio is an indicator of stability; it is obtained by dividing the boat's displacement by the mass of the ballast. Since the stability depends also of the hull shapes and the position of the center of gravity, only the boats with similar ballast arrangements and hull shapes should be compared. The higher the ballast ratio is, the greater is the stability.: 36 %
Critical hull speed iAs a ship moves in the water, it creates standing waves that oppose its movement. This effect increases dramatically the resistance when the boat reaches a speed-length ratio (speed-length ratio is the ratio between the speed in knots and the square root of the waterline length in feet) of about 1.2 (corresponding to a Froude Number of 0.35) . This very sharp rise in resistance, between speed-length ratio of 1.2 to 1.5, is insurmountable for heavy sailboats and so becomes an apparent barrier. This leads to the concept of "hull speed". The hull speed is obtained by multiplying the square root of the waterline length (in feet) by 1.34.: 7.15 knots
