Hunter 456 Deep draft

Sailboat specifications

The Hunter 456 is a 44’4” (13.49m) cruising sailboat designed by Hunter Design (United States). She was built since 2003 (and now discontinued) by Marlow Hunter (United States). The Deep draft version displays a deeper fin allowing a lower center of gravity and extra performance especially upwind.

The Hunter 456 is as well listed, on Boat-Specs.com, in Shoal draft version (see all the versions compared).

Hunter 456's main features

Model: Hunter 456
Version: Deep draft
Hull type: Monohull
Category: Offshore cruising sailboat
Sailboat builder: Marlow Hunter
Sailboat designer: Hunter Design
Country: United States
Construction: GRP (glass reinforced polyester):
Single skin bottom, sandwich sides and deck: foam fiberglass polyester with Kevlar reinforcements
First built hull: 2003
Last built hull: Discontinued
Appendages: Keel : fin without bulb
Helm: Single helm wheel
Rudder: Single spade rudder
Unsinkable: No
Trailerable: No
EC design category iThe CE design category indicates the ability to cope with certain weather conditions (the sailboat is designed for these conditions) A: Wind < force 9, Waves < 10m B: Wind < force 8, Waves < 8m C: Wind < force 6, Waves < 4m D: Wind < force 4, Waves < 0,5m: A
Standard public price ex. VAT (indicative only): N/A €

Hunter 456's main dimensions

Overall length: 46’ 1”14.05 m
Hull length: 44’ 4”13.49 m
Waterline length: 39’ 8”12.09 m
Beam (width): 14’4.27 m
Draft: 6’ 6”1.98 m
Mast height from D_WL: 63’19.2 m
Light displacement (M_LC): 26204 lb11886 kg
Ballast weight: 9689 lb4395 kg
Ballast type: Lead

Hunter 456's rig and sails

Upwind sail area: 1000 ft²92.9 m²
I iFore triangle height (from mast foot to fore stay top attachment): 55’ 5”16.9 m
J iFore triangle base (from mast foot to bottom of forestay): 16’ 11”5.16 m
P iMainsail hoist measurement (from tack to head): 49’ 11”15.22 m
E iMainsail foot measurement (from tack to clew): 16’ 10”5.13 m
Rigging type: Sloop Marconi masthead
Mast configuration: Deck stepped mast
Rotating spars: No
Number of levels of spreaders: 2
Spreaders angle: Swept-back (Bergström)
Spars construction: Aluminum spars
Standing rigging: 1x19 strand wire discontinuous

Hunter 456's performances

Upwind sail area to displacement iThe ratio sail area to displacement is obtained by dividing the sail area by the boat's displaced volume to the power two-thirds. The ratio sail area to displacement can be used to compare the relative sail plan of different sailboats no matter what their size. Upwind: under 18 the ratio indicates a cruise oriented sailboat with limited performances especially in light wind, while over 25 it indicates a fast sailboat.: 192 ft²/T17.84 m²/T
Displacement-length ratio (DLR) iThe Displacement Length Ratio (DLR) is a figure that points out the boat's weight compared to its waterline length. The DLR is obtained by dividing the boat's displacement in tons by the cube of one one-hundredth of the waterline length (in feet). The DLR can be used to compare the relative mass of different sailboats no matter what their length: a DLR less than 180 is indicative of a really light sailboat (race boat made for planning), while a DLR greater than 300 is indicative of a heavy cruising sailboat.: 190
Ballast ratio iThe Ballast ratio is an indicator of stability; it is obtained by dividing the boat's displacement by the mass of the ballast. Since the stability depends also of the hull shapes and the position of the center of gravity, only the boats with similar ballast arrangements and hull shapes should be compared. The higher the ballast ratio is, the greater is the stability.: 37 %
