Tonic 23 Keel and centerboard

Sailboat specifications

The Tonic 23 is a 22’7” (6.9m) cruising sailboat designed by Harlé-Mortain (France). She was built between 1985 and 1992 by Jeanneau (France). The Keel and centerboard version features a centerboard inside of a short fin-keel allowing shoal draft while maintaining upwind capabilities.

The Tonic 23 is as well listed, on Boat-Specs.com, in Fin keel version (see all the versions compared).

Tonic 23's main features

Model: Tonic 23
Version: Keel and centerboard
Hull type: Monohull
Category: Coastal cruising sailboat
Sailboat builder: Jeanneau
Sailboat designer: Harlé-Mortain
Country: France
Construction: GRP (glass reinforced polyester):
- Hull: Single skin fiberglass polyester
- Deck: Sandwich balsa fiberglass polyester
Number of hulls built: About 750
First built hull: 1985
Last built hull: 1992
Appendages: Centerboard : pivoting centerboard in the keel
Helm: Single tiller
Rudder: Single transom hung rudder
Unsinkable: No
Trailerable: Yes
Former French navigation category: 3
Standard public price ex. VAT (indicative only): N/A €

Tonic 23's main dimensions

Overall length: 24’7.3 m
Hull length: 22’ 7”6.9 m
Waterline length: 20’ 4”6.2 m
Beam (width): 8’ 2”2.5 m
Waterline beam (width): 7’ 2”2.18 m
Draft: 4’ 6”1.38 m
Draft when appendages up: 2’ 4”0.7 m
Mast height from D_WL: 38’ 5”11.7 m
Fore freeboard: 3’ 4”1.02 m
Mid-ship freeboard: 2’ 11”0.88 m
Light displacement (M_LC): 2932 lb1330 kg
Maximum displacement (M_LDC): 4101 lb1860 kg
Ballast weight: 1058 lb480 kg
Ballast type: Cast iron exterior ballast with steel centerboard
French customs tonnage: 4.48 Tx

Tonic 23's rig and sails

Upwind sail area: 316 ft²29.4 m²
Downwind sail area: 521 ft²48.4 m²
Mainsail area: 157 ft²14.6 m²
Genoa area: 159 ft²14.8 m²
Solent area: 140 ft²13 m²
Jib area: 86 ft²8 m²
Stormjib area: 43 ft²4 m²
Symmetric spinnaker area: 364 ft²33.8 m²
I iFore triangle height (from mast foot to fore stay top attachment): 23’ 7”7.2 m
J iFore triangle base (from mast foot to bottom of forestay): 7’ 11”2.4 m
P iMainsail hoist measurement (from tack to head): 27’ 11”8.5 m
E iMainsail foot measurement (from tack to clew): 10’3.06 m
Rigging type: Sloop Marconi fractional
Mast configuration: Deck stepped mast
Rotating spars: No
Number of levels of spreaders: 1
Spreaders angle: Swept-back
Spars construction: Aluminum spars
Standing rigging: Continuous

Tonic 23's performances

HN (French rating) iHN or "Handicap Nationale" is an empirical rating system used in France allowing various monohulls, of different sizes and designs, to race each other fairly. It is particularly suitable for cruiser and cruiser-racer. Therefore, by comparing these values, we can have an indication of the relative speed of 2 boats.: 9.0
Upwind sail area to displacement iThe ratio sail area to displacement is obtained by dividing the sail area by the boat's displaced volume to the power two-thirds. The ratio sail area to displacement can be used to compare the relative sail plan of different sailboats no matter what their size. Upwind: under 18 the ratio indicates a cruise oriented sailboat with limited performances especially in light wind, while over 25 it indicates a fast sailboat.: 262 ft²/T24.31 m²/T
Downwind sail area to displacement iThe ratio sail area to displacement is obtained by dividing the sail area by the boat's displaced volume to the power two-thirds. The ratio sail area to displacement can be used to compare the relative sail plan of different sailboats no matter what their size.: 431 ft²/T40.02 m²/T
Displacement-length ratio (DLR) iThe Displacement Length Ratio (DLR) is a figure that points out the boat's weight compared to its waterline length. The DLR is obtained by dividing the boat's displacement in tons by the cube of one one-hundredth of the waterline length (in feet). The DLR can be used to compare the relative mass of different sailboats no matter what their length: a DLR less than 180 is indicative of a really light sailboat (race boat made for planning), while a DLR greater than 300 is indicative of a heavy cruising sailboat.: 158
Ballast ratio iThe Ballast ratio is an indicator of stability; it is obtained by dividing the boat's displacement by the mass of the ballast. Since the stability depends also of the hull shapes and the position of the center of gravity, only the boats with similar ballast arrangements and hull shapes should be compared. The higher the ballast ratio is, the greater is the stability.: 36 %
Wetted area: 133 ft²12.35 m²
Righting moment @ 1° iThe righting moment is a moment (torque) that tends to restore a boat to its previous position after heeling. Its value corresponds to the torque needed to heel the boat for this angle. Higher the righting moment is for an angle, greater is the stability.: 192 lb.ft27 kg.m
Maximum transverse section: 7 ft²0.64 m²
Critical hull speed iAs a ship moves in the water, it creates standing waves that oppose its movement. This effect increases dramatically the resistance when the boat reaches a speed-length ratio (speed-length ratio is the ratio between the speed in knots and the square root of the waterline length in feet) of about 1.2 (corresponding to a Froude Number of 0.35) . This very sharp rise in resistance, between speed-length ratio of 1.2 to 1.5, is insurmountable for heavy sailboats and so becomes an apparent barrier. This leads to the concept of "hull speed". The hull speed is obtained by multiplying the square root of the waterline length (in feet) by 1.34.: 6.04 knots
