Etap 30i Deep draft

Sailboat specifications

The Etap 30i is a 29’4” (8.92m) cruising sailboat designed by Mortain & Mavrikios Yacht Design (France). She was built between 1995 and 2005 by Etap (Belgium) with 280 hulls completed. The Deep draft version offers a deeper L-shaped keel bringing extra performance especially upwind.

Etap 30i's main features

Model: Etap 30i
Version: Deep draft
Hull type: Monohull
Category: Cruising sailboat
Sailboat builder: Etap
Sailboat designer: Mortain & Mavrikios Yacht Design
Country: Belgium
Construction: GRP (glass reinforced polyester):
Sandwich foam fiberglass polyester
Number of hulls built: 280
First built hull: 1995
Last built hull: 2005
Appendages: Keel : L-shaped keel (with bulb)
Helm: Single tiller (evs: Etap vertical steering system in option)
Rudder: Single spade rudder
Unsinkable: Yes
Trailerable: No
Former French navigation category: 2
Standard public price ex. VAT (indicative only): N/A €

Etap 30i's main dimensions

Overall length: 30’ 8”9.35 m
Hull length: 29’ 4”8.92 m
Waterline length: 26’ 2”8 m
Beam (width): 10’ 5”3.16 m
Waterline beam (width): 8’ 2”2.5 m
Draft: 5’ 7”1.7 m
Mast height from D_WL: 44’ 6”13.56 m
Fore freeboard: 4’ 1”1.25 m
Mid-ship freeboard: 3’ 8”1.13 m
Light displacement (M_LC): 7716 lb3500 kg
Ballast weight: 2425 lb1100 kg
Ballast type: Cast iron
French customs tonnage: 7.93 Tx

Etap 30i's rig and sails

Upwind sail area: 437 ft²40.6 m²
Downwind sail area: 772 ft²71.75 m²
Mainsail area: 262 ft²24.3 m²
Genoa area: 175 ft²16.3 m²
Jib area: 137 ft²12.7 m²
Symmetric spinnaker area: 511 ft²47.45 m²
I iFore triangle height (from mast foot to fore stay top attachment): 33’ 6”10.21 m
J iFore triangle base (from mast foot to bottom of forestay): 9’ 6”2.91 m
P iMainsail hoist measurement (from tack to head): 35’ 7”10.86 m
E iMainsail foot measurement (from tack to clew): 12’ 6”3.8 m
Rigging type: Sloop Marconi 7/8
Mast configuration: Deck stepped mast
Rotating spars: No
Number of levels of spreaders: 1
Spreaders angle: Swept-back
Spars construction: Aluminum spars
Standing rigging: 1x19 strand wire continuous

Etap 30i's performances

HN (French rating) iHN or "Handicap Nationale" is an empirical rating system used in France allowing various monohulls, of different sizes and designs, to race each other fairly. It is particularly suitable for cruiser and cruiser-racer. Therefore, by comparing these values, we can have an indication of the relative speed of 2 boats.: 16.0
Upwind sail area to displacement iThe ratio sail area to displacement is obtained by dividing the sail area by the boat's displaced volume to the power two-thirds. The ratio sail area to displacement can be used to compare the relative sail plan of different sailboats no matter what their size. Upwind: under 18 the ratio indicates a cruise oriented sailboat with limited performances especially in light wind, while over 25 it indicates a fast sailboat.: 190 ft²/T17.61 m²/T
Downwind sail area to displacement iThe ratio sail area to displacement is obtained by dividing the sail area by the boat's displaced volume to the power two-thirds. The ratio sail area to displacement can be used to compare the relative sail plan of different sailboats no matter what their size.: 335 ft²/T31.13 m²/T
Displacement-length ratio (DLR) iThe Displacement Length Ratio (DLR) is a figure that points out the boat's weight compared to its waterline length. The DLR is obtained by dividing the boat's displacement in tons by the cube of one one-hundredth of the waterline length (in feet). The DLR can be used to compare the relative mass of different sailboats no matter what their length: a DLR less than 180 is indicative of a really light sailboat (race boat made for planning), while a DLR greater than 300 is indicative of a heavy cruising sailboat.: 194
Ballast ratio iThe Ballast ratio is an indicator of stability; it is obtained by dividing the boat's displacement by the mass of the ballast. Since the stability depends also of the hull shapes and the position of the center of gravity, only the boats with similar ballast arrangements and hull shapes should be compared. The higher the ballast ratio is, the greater is the stability.: 31 %
Critical hull speed iAs a ship moves in the water, it creates standing waves that oppose its movement. This effect increases dramatically the resistance when the boat reaches a speed-length ratio (speed-length ratio is the ratio between the speed in knots and the square root of the waterline length in feet) of about 1.2 (corresponding to a Froude Number of 0.35) . This very sharp rise in resistance, between speed-length ratio of 1.2 to 1.5, is insurmountable for heavy sailboats and so becomes an apparent barrier. This leads to the concept of "hull speed". The hull speed is obtained by multiplying the square root of the waterline length (in feet) by 1.34.: 6.87 knots
